Industry Parameters:
Operating Voltage: 220V
Operating Frequency: 315MHz (433MHz or other frequencies can be customized)
Receiver Sensitivity: -95dB
Encoding Method: Learning type
Operating Mode: Switchable between inching/interlocking/self-locking
Output Method: One set of switch signals
Maximum Load: 3A
Mainly used in remote control applications for electric doors, windows, switches, automotive parts, security alarms, etc.

Industry Parameters:
1. Operating Voltage: 220V
2. Operating Frequency: 315MHz (433MHz or other frequencies can be customized)
3. Receiver Sensitivity: -95dB
4. Encoding Method: Learning type
5. Operating Mode: Switchable between inching/interlocking/self-locking
6. Output Method: One set of switch signals
7. Maximum Load: 3A
Mainly used in remote control applications for electric doors, windows, switches, automotive parts, security alarms, etc.

Main Technical Specifications
Operating Voltage: 220V
Operating Frequency: 433MHz (315MHz or other frequencies can be customized)
Encoding Method: Learning type
Operating Mode: 3-second jog/interlock/jog can be switched via a jumper cap (without a jumper cap, there is a direct jog or 3-second jog program, which may vary depending on the customer)
Output Method: One set of switch signals
Maximum Load: 10A
Main applications include remote control of electric doors, windows, switches, automotive parts, security alarms, etc.

Industry Specifications
1. Operating Voltage: A220V
2. Operating Frequency: 315MHz (433MHz or other frequencies can be customized)
3. Receiver Sensitivity: -95dB
4. Encoding Method: Learning type
5. Operating Mode: Switchable between inching/interlocking/self-locking
6. Output Method: Powered output
7. Maximum Load: 10A
8. Dimensions: 88*39*23 mm

Main Technical Specifications
Operating Voltage: 220V
Operating Frequency: 433MHz (315MHz or other frequencies can be customized)
Encoding Method: Learning type
Operating Mode: 3-second jog/interlock/jog can be switched via a jumper cap (without a jumper cap, there is a direct jog or 3-second jog program, which may vary depending on the customer)
Output Method: 2-way output
Maximum Load: 3A
Main applications include remote control of electric doors, windows, switches, automotive parts, security alarms, etc.

Main Technical Specifications
Operating Voltage: 220V
Operating Frequency: 433MHz (315MHz or other frequencies can be customized)
Encoding Method: Learning type
Operating Mode: 3-second jog/interlock/jog can be switched via a jumper cap (without a jumper cap, there is a direct jog or 3-second jog program, which may vary depending on the customer)
Output Method: 2-way output
Maximum Load: 10A
Main applications include remote control of electric doors, windows, switches, automotive parts, security alarms, etc.

Main Technical Specifications
Operating Voltage: 220V
Operating Frequency: 433MHz (315MHz or other frequencies can be customized)
Encoding Method: Learning type
Operating Mode: 3-second jog/interlock/jog can be switched via a jumper cap (without a jumper cap, there is a direct jog or 3-second jog program, which may vary depending on the customer)
Output Method: Three-way output
Maximum Load: 3A
Main applications include remote control of electric doors, windows, switches, automotive parts, security alarms, etc.

Main Technical Specifications
Operating Voltage: 220V
Operating Frequency: 433MHz (315MHz or other frequencies can be customized)
Encoding Method: Learning type
Operating Mode: 3-second jog/interlock/jog can be switched via a jumper cap (without a jumper cap, there is a direct jog or 3-second jog program, which may vary depending on the customer)
Output Method: Four-way output
Maximum Load: 3A
Main applications include remote control of electric doors, windows, switches, automotive parts, security alarms, etc.

Features:
220V single-channel ultra-high power, 30A large relay, load power up to five or six kilowatts, very stable voltage step-down via transformer, learning type, compatible with various RF remote controls, mainly used for high-power lighting and electrical appliance control in homes, hotels, factories, warehouses, and conference rooms, such as crystal lamps, light panels, and light strips.

Features:
220V dual-channel ultra-high power, 30A large relay, load power up to five or six kilowatts, very stable voltage through transformer step-down, learning type, compatible with various RF remote controls, mainly used for high-power lighting and electrical appliance control in homes, hotels, factories, warehouses, and conference rooms, such as crystal lamps, light panels, and light strips.

Features:
220V three-channel ultra-high power, 30A large relay, load power up to five or six kilowatts, very stable voltage through transformer step-down, learning type, compatible with various RF remote controls, mainly used for high-power lighting and electrical appliance control in homes, hotels, factories, warehouses, and conference rooms, such as crystal lamps, light panels, and light strips.

Features:
220V single-channel high power, 30A large relay, manual control buttons with illuminated status indicators; pressing the remote control button activates the corresponding relay and illuminates the light in that relay. Load power can reach five to six kilowatts. Voltage is stepped down via a transformer for high stability. It is a learning type and compatible with various RF remote controls. Primarily used for high-power lighting and electrical appliance control in homes, hotels, factories, warehouses, and conference rooms, such as crystal chandeliers, light panels, and light strips.
